Legacy Outback Limited AWD F4-2.5L DOHC (1998)
3) Remove rear exhaust pipe bracket from rubber cushion.
NOTE: To facilitate removal, apply a coat of SUBARU CRC or equivalent to pipe bracket in advance.
SUBARU CRC (Part No. 004301003)
B: Installation
CAUTION: Replace gaskets with new ones.
1) Install rear exhaust pipe bracket to rubber cushion.
NOTE: To facilitate installation, apply a coat of SUBARU CRC or equivalent to mating area of rubber cushion in advance.
SUBARU CRC (Part No. 004301003)
2) Install rear exhaust pipe to muffler.
Tightening torque: 48 ± 5 Nm (4.9 ± 0.5 kg-m, 35.4 ± 3.6 ft. lbs.)
3) Install rear exhaust pipe to center exhaust pipe.
Tightening torque: 18 ± 5 Nm (1.8 ± 45 kg-m, 13.0 ± 3.6 ft. lbs.)
