Legacy Outback Limited AWD F4-2.5L DOHC (1998)
Shift Pattern Select Control
Shift pattern is selectable automatically between a normal pattern suitable for ordinary economy running and a power pattern suitable for climbing
uphill or rapid acceleration.
In the power pattern, the shift down point and shift up point are set higher than those of the normal pattern.
1. Normal pattern to power pattern
Depending on throttle opening and vehicle speed, 16 areas as shown in the figure are set. Accelerator depression speed for pattern changeover is
set for each area.
When the accelerator depression speed exceeds this set value, the pattern changes from normal to power.
