Outback F4-2.5L (2008)
Knock Sensor: Service and Repair
Knock Sensor
REMOVAL
1. Disconnect the ground cable from the battery.
2. Remove the air intake chamber.
3. Disconnect the knock sensor connector.
4. Remove the knock sensor from the cylinder block.
INSTALLATION
1. Install the knock sensor to the cylinder block.
NOTE: Extraction area of knock sensor cord must be positioned at a 60° angle relative to the engine rear.
