Esteem GLX Wagon Plus L4-1.8L (1999)
4. With marks on washer and frame marked before removal aligned to each other, tighten bolts and nut temporarily by hand.
3. For vehicles equipped with ABS, attach ABS wheel speed sensor pipe to No.2 control rod.
4. Install stabilizer bar.
Tightening Torque
(a): 23 Nm (2.3 kg-m, 17.0 ft. lbs.)
(b): 50 Nm (5.0 kg-m, 36.5 ft. lbs.)
5. Lower hoist and bounce vehicle up and down to stabilize suspension.
6. Tighten control rod bolts and nuts to specified torque with vehicle weight on suspension.
NOTE:
^
It is the most desirable to have vehicle off hoist and in non-loaded condition when tightening them.
^
Tighten No.2 control rod inner nut with match marks aligned.
Tightening Torque (a): 90 Nm (9.0 kg-m, 65.0 ft. lbs.)
7. Install wheels (right & left) and lower hoist.
8. Check rear toe and adjust it as necessary.
9. Install suspension frame cap.
