Kizashi AWD L4-2.4L (2010)
Glove Box Lamp: Service and Repair
Glove Box Light Removal and Installation
Removal
1. Remove service manual case.
2. Turn socket (1) counterclockwise to remove bulb.
Installation
Reverse removal procedure.
