4 Runner 2WD V6-4.0L (1GR-FE) (2006)
OVERHAUL
1. REMOVE FRONT DISC WHEEL
2. INSPECT FRONT SUSPENSION ARM SUB-ASSEMBLY LOWER NO. 1 LH
a. Install the hub nuts to the disc.
b. Using a dial indicator, check the lower ball joint for excessive play when you push the hub nuts up and down with a force of 294 N (30 kgf, 66
lbs.).
Maximum: 0.5 mm (0.020 inch)
HINT: If it is not within the specification, replace the lower arm.
