Camry Coupe 2-Door V6-3.0L (1MZ-FE) (1996)
/Page-131001.png)
Camshaft Position Sensor: Service and Repair
CAMSHAFT POSITION SENSOR REMOVAL
-
REMOVE CAMSHAFT POSITION SENSOR
(a) Disconnect the camshaft position sensor connector.
(b) Remove the 2 bolts and camshaft position sensor.
Torque: 8 Nm (80 kgf.cm, 69 in.lb)
CAMSHAFT POSITION SENSOR INSTALLATION
-
INSTALLATION IS IN THE REVERSE ORDER OF REMOVAL.
