Camry Coupe 2-Door V6-3.0L (1MZ-FE) (1996)
(a) Using a torx wrench: T40 (Part No.09042-00020), loosen and tighten the 3 screws.
(b) Disconnect and connect connector.
NOTICE: Removal and installation of the connector is done with the sensor assembly installed.
(c) Using a torx wrench: T40 (Part No.09042-00020), tighten the 3 screws.
Torque: 20 N.m (200 kgf.cm, 14 ft.lbf)
NOTICE:
-
Make sure the sensor assembly is installed to the specified torque.
-
If the sensor assembly has been dropped, or there are cracks, dents or other defects in the case, bracket or connector, replace the sensor
assembly with a new one.
-
When installing the sensor assembly, take care that the airbag wiring does not interfere with other parts and is not pinched between other parts.
-
After Installation, shake the sensor assembly to check that there is no looseness.
3. Install the removed parts.
