Camry Coupe 2-Door V6-3.0L (1MZ-FE) (1996)
/Page-1522001.png)
Stabilizer Bar: Service and Repair
Front
Fig. 6 Exploded View Of Stabilizer Bar.
1.
Raise and support vehicle then remove front wheels.
2.
Remove left and right fender apron seals, then disconnect left and right tie rod ends from steering knuckles using ball joint puller 09628-62011 or
equivalent.
3.
Remove left and right stabilizer bar links, left and right bushing retainers and left and right bushings, Fig. 6.
4.
Remove front exhaust pipe, then the steering gear mounting nuts and bolts.
5.
Lift steering gear up, then remove stabilizer bar.
6.
Reverse procedure to install.
