Camry Wagon L4-132 2164cc 2.2L DOHC (5S-FE) (1995)
/Page-1698001.png)
Air Door Actuator / Motor: Testing and Inspection
Air Outlet Servomotor
INSPECTION
1. Connect the positive (+) lead from the battery to terminal 6 and the negative (-) lead to terminal 7.
2. Connect the negative (-) lead from the battery to each terminal and check that the arm rotates to each position as shown below.
If operation is not as specified, replace the servomotor.
