Camry XLE Sedan L4-2164cc 2.2L DOHC (5S-FE) MFI (1999)
_mfi/Page-1729001.png)
Air Door Actuator / Motor: Service and Repair
REMOVAL
1. REMOVE THESE PARTS:
a. No.1 lower instrument panel
b. LH instrument lower panel
2. REMOVE SERVOMOTOR
a. Release the claw and pull out the plate.
b. Disconnect the connector.
c. Remove the 3 screws and servomotor.
INSTALLATION
1. INSTALL SERVOMOTOR
a. Install servomotor with the 3 screws.
b. Connect he connector.
