Celica Coupe L4-107.5 1762cc 1.8L DOHC (7A-FE) (1995)
ABS Light: Testing and Inspection
ABS Warning Light Circuit
CIRCUIT DESCRIPTION
If the ECU detects trouble, it lights the ABS warning light while at the same time prohibiting ABS control. At this time, the ECU records a diagnostic
trouble code in memory.
After removing the short pin of the DLC1 connect terminals Tc and E1 of DLC1 to make the ABS warning light blink and output the diagnostic trouble
code.
Wiring Diagram
INSPECTION PROCEDURE
Perform troubleshooting in accordance with the chart below for each trouble symptom.
