Celica GT L4-1.8L (1ZZ-FE) (2001)
/Page-363001.png)
Ignition Timing Connector: Locations
Connector View Of DLC3
Position Of Parts In Instrument Panel (Part 1)
Connect terminals 13 (TC) and 4 (CG) of the DLC3 to check the ignition timing.
