Celica GT L4-1.8L (1ZZ-FE) (2001)
/Page-1370001.png)
Key Reminder Switch: Pinout Values and Diagnostic Parameters
Key Reminder and Seat Belt Warning
B8 BUCKLE SW LH
1 - 2 : Opened with the driver's seat belt in use.
D3 DOOR COURTESY SW LH
1 - GROUND: Closed with the LH door open.
U1 UNLOCK WARNING SW
2 - 1 : Closed with the ignition key in the cylinder.
