Celica GT L4-1.8L (1ZZ-FE) (2001)
(a) Remove the 2 bolts, brake caliper and disc.
(b) Support the brake caliper securely.
(c) Using a dial indicator, check the backlash near the center of the axle hub.
Maximum: 0.05 mm (0.0020 inch)
If the backlash exceeds the maximum, replace the bearing.
(d) Using a dial indicator, check the deviation at the surface of the axle hub outside the hub bolt.
Maximum: 0.07 mm (0.0028 inch)
If the deviation exceeds the maximum, replace the axle hub.
(e) Install the disc, 2 bolts and brake caliper.
Torque: 107 Nm (1,090 kgf-cm, 79 ft. lbs.)
3. REMOVE DRIVE SHAFT LOCK NUT
(a) Using SST and a hammer, unstake the staked part of the lock nut.
SST 09930-00010
(b) While applying the brakes, remove the nut.
Torque: 216 Nm (2,200 kgf-cm, 159 ft. lbs.)
(c) Remove the brake caliper and disc.
(d) Support the brake caliper securely.
4. w/ ABS:
REMOVE ABS SPEED SENSOR
Torque: 8.0 Nm (82 kgf-cm, 71 inch lbs.)
