Celica GT L4-1.8L (1ZZ-FE) (2001)
SST 09628-62011
2. REMOVE AXLE HUB
(a) Using SST, remove the axle hub.
SST 09520-00031 (09520-00040, 09521-00010, 09521-00020)
(b) Using SST and a press, remove the inner race (outside) from the axle hub.
SST 09555-55010, 09950-60010 (09951-00380), 09950-70010 (09951-07150)
3. REMOVE DUST COVER
Using a torx socket (T30), remove the 3 bolts and dust cover.
4. REMOVE BEARING FROM STEERING KNUCKLE
(a) Using snap ring pliers, remove the snap ring.
(b) Place the inner race on the outside of the bearing.
(c) Using SST and a press, remove the bearing.
SST 09527-17011, 09950-60010 (09951-00650), 09951-70010 (09951-07150)
REASSEMBLY
1. INSTALL BEARING
(a) Using SST and a press, install a new bearing to the steering knuckle.
SST 09950-60020 (09951-00730), 09950-70010 (09951-07150)
(b) Using snap ring pliers, install a new snap ring.
2. INSTALL DUST COVER
