Celica GT L4-1.8L (1ZZ-FE) (2001)

Page 3
background image

DISASSEMBLY

REMOVE COIL SPRING

(a) Using SST, compress the coil spring.

SST 09727-30021 (09727-00010, 09727-00021, 09727-00031)
