Matrix AWD L4-2.4L (2AZ-FE) (2009)
Control Module HVAC: Service and Repair
Installation
HEATING / AIR CONDITIONING: AIR CONDITIONING AMPLIFIER: INSTALLATION
INSTALLATION
1. INSTALL AIR CONDITIONING AMPLIFIER ASSEMBLY
(a) Install the air conditioning amplifier assembly as shown in the illustration.
(b) Install the screw.
(c) Connect the connector.
2. INSTALL FRONT NO. 1 CONSOLE BOX INSERT See: Body and Frame/Interior Moulding / Trim/Dashboard / Instrument Panel/Service and
Repair/Lower Instrument Panel/Installation
