RAV4 4WD V6-3.5L (2GR-FE) (2006)
Canister Purge Control Valve: Service and Repair
REMOVAL
1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt
pretensioner activation.
2. REMOVE V-BANK COVER SUB-ASSEMBLY
3. REMOVE PURGE VSV
a. Disconnect the purge VSV connector.
b. Disconnect the wire harness clamp.
c. Disconnect the 2 purge line hoses from the purge VSV.
d. Remove the bolt and purge VSV.
INSTALLATION
1. INSTALL PURGE VSV
a. Install the purge VSV with the bolt.
Torque: 10 N.m (102 kgf.cm, 7 in.*lbf)
b. Connect the 2 purge line hoses to the purge VSV.
c. Connect the wire harness clamp.
d. Connect the purge VSV connector.
2. INSTALL V-BANK COVER SUB-ASSEMBLY
