Sequoia 2WD V8-4.7L (2UZ-FE) (2003)
/Page-790001.png)
Transmission Speed Sensor: Service and Repair
O/D Direct Clutch Speed Sensor
O/D DIRECT CLUTCH SPEED SENSOR
ON-VEHICLE REPAIR
1. DISCONNECT O/D DIRECT CLUTCH SPEED SENSOR CONNECTOR
2. REMOVE O/D DIRECT CLUTCH SPEED SENSOR
a. Remove the bolt and O/D direct clutch speed sensor.
b. Remove the O-ring from the O/D direct clutch speed sensor.
3. INSTALL O/D DIRECT CLUTCH SPEED SENSOR
a. Coat a new O-ring with ATF and install it to the O/D direct clutch speed sensor.
b. Install the O/D direct clutch speed sensor to the transmission case with the bolt.
Torque: 5.4 Nm (55 kgf-cm, 48 inch lbs.)
4. CONNECT O/D DIRECT CLUTCH SPEED SENSOR CONNECTOR
