Sequoia 2WD V8-4.7L (2UZ-FE) (2003)
/Page-1185001.png)
Control Arm: Service and Repair
Front
Lower
REMOVAL
1. REMOVE RH AND LH FRONT WHEELS
2. DISCONNECT RH AND LH TIE ROD ENDS
a. Remove the cotter pin and nut.
