Sequoia 4WD V8-4.7L (2UZ-FE) (2006)
Camshaft Position Sensor: All Technical Service Bulletins
Engine Controls - MIL ON/DTC's P0335/P1340/Int. No Start
ENGINE
EG052-06
Title:
M.I.L. "ON" DTC P0335 AND/OR P1340:
INTERMITTENT HOT SOAK NO-START
Models:
'05 - '06 4Runner (2UZ-FE), Land Cruiser, Sequoia, & Tundra (2UZ- FE)
August 24, 2006
Introduction
Some customers may experience a M.I.L. "ON" condition with DTCs P0335 and/or P1340 with intermittent hot soak no-start. The camshaft position
sensor assembly has been improved to prevent this concern.
^
P0335 (Crankshaft Position Sensor "A" Circuit)
^
P1340 (Camshaft Position Sensor "A" [Bank 1 Sensor 1])
Applicable Vehicles
^
2005 - 2006 model year 4Runner and Tundra vehicles equipped with the 2UZ-FE engine.
^
2005 - 2006 model year Land Cruiser and Sequoia vehicles.
Parts Information
Warranty Information
Applicable Warranty*:
This repair is covered under the Toyota Comprehensive Warranty. This warranty is in effect for 36 months or 36,000 miles, whichever occurs first, from
the vehicle's in-service date.
* Warranty application is limited to correction of a problem based upon a customer's specific complaint.
