Sequoia 4WD V8-4.7L (2UZ-FE) (2006)
e. Check that there is no looseness in the installation parts of the center airbag sensor assembly.
f.
Connect the holder (with connectors) to the center airbag sensor assembly.
g. Check that the waterproof sheet is properly set.
2. INSTALL FRONT CONSOLE BOX
3. INSTALL REAR CONSOLE BOX
4. INSTALL UPPER CONSOLE PANEL
5. INSTALL SHIFTING HOLE COVER
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION
a. Perform initialization.
HINT: Some systems need initialization when disconnecting the cable from the negative battery terminal.
8. INSPECT SRS WARNING LIGHT
a. Inspect the SRS warning light.
