T100 Pickup 4WD V6-180.5 2959cc 3.0L SOHC (3VZ-E) (1993)
/Page-1124001.png)
Brake Pad: Service and Repair
Fig. 9 Exploded View Of Disc Brake Assembly.
1.
Raise and support front of vehicle, then remove tire and wheel assembly.
2.
Remove clip and hole pins, Fig. 9.
3.
Remove anti-rattle spring and shim(s) if equipped, then remove brake pads.
4.
Lubricate caliper housing with suitable brake grease at pad contact points.
5.
Reverse procedure to install.
