Tacoma Extra Cab Limited 4WD V6-3.4L (5VZ-FE) (2000)
/Page-673002.png)
(b) Connect the positive (+) lead from the ohmmeter to terminal 5 and the negative (-) lead to terminal 4.
(c) Check that there is continuity between terminals 4 and 5.
(d) Connect the positive (+) lead from the battery to terminal 3 and the negative (-) lead to terminal 2.
(e) Connect the positive (+) lead from the ohmmeter to terminal 6 and the negative (-) lead to terminal 4.
(f) Check that there is continuity between terminal 4 and 6.
If continuity is not as specified, replace the actuator assembly.
