Corsa C

Structure of the cooling system - Z 13 DT DOHC diesel engine

The cooling system of the Z 13 DT engine consists of the following components:

Object Number: 2413723 Size: DEFAULT

  1. Inlet side
  2. Outlet side
1. Thermostat
2. Exhaust gas recirculation cooler
3. Heat exchanger
4. Coolant pump
