Engine to gearbox M10

45 Nm

Engine to gearbox M12

75 Nm

Flywheel cover plate

10 Nm

Drive shafts to flanged shafts

45 Nm

Exhaust pipe to manifold

40 Nm

Engine/gearbox carrier to body M10

40 Nm
