Golf Mk5

Modification in area of deep groove ball bearing
Modification in area of deep groove ball bearing
From gearbox date 10 04 6 through around gearbox date 20 01 8:
One washer above and one below bearing seat for deep groove ball bearing → Item.

Above bearing seat:
  N35-10149
Bearing seatWasher above bearing seat
Through gearbox date 09 04 6Dimension „a“ = 10 mmno
From gearbox date 10 04 6
through around gearbox date 20 01 8:		Dimension „a“ = 10.7 mmyes
From around gearbox date 21 01 8Below bearing seat:
flat for deep groove ball bearing		no

Beneath bearing seat -arrow-:

From gearbox date 10 04 6 through around gearbox date 20 01 8 slightly deeper
In order for the washer beneath the deep groove ball bearing → Item to fit, the bearing seat for the deep groove ball bearing -arrow- is machined out slightly.
  N35-10150
Beneath bearing seat:Washer beneath bearing seat
Through gearbox date
09 04 6		Not further machinedno
From gearbox date 10 04 6
through around gearbox date 20 01 8:		Machined slightly deeperyes
From around gearbox date 21 01 8Flat -B- for deep groove ball bearing -A-no


From around gearbox date 21 01 8, flats on deep groove ball bearing -A- and on bearing support -B- of gearbox housing
l  If the flats are present, no washer must be placed above or below the deep groove ball bearing.
  N34-11101
