Golf L4-1.8L Turbo (AWW) (2003)
-
Install steering wheel so marked line -arrow A- on steering wheel and center punch mark -arrow B- on steering column align.
-
Steering columns supplied as replacement parts do not have a center punch mark.
-
Install steering wheel bolt and tighten.
-
Align ignition switch horizontally.
-
Set gap -a- to approx. 2.5 mm. (0.10 inch).
-
Tighten bolt -3-.
-
Remove steering wheel again.
-
Install trim in reverse order of removal.
-
Install steering wheel bolt and tighten.
Multi-point socket head bolt: 50 Nm (37 lbs.)
-
Make one center punch mark on multi-point socket head bolt.
Note:
Multi-point socket head bolts with five center punch marks must be replaced.
If a new steering column has been installed, center point can be determined via test drive.
-
Install steering wheel in straight ahead position.
-
Mark steering column after center point has been determined
A - Mark on hub of steering wheel
B - Mark on steering column
