GTI L4-2.0L Turbo (CBFA) (2008)
/Page-1816027.png)
Installing
-
Installation is performed in the reverse order of removal.
NOTE: When installing, bolts must be installed in the sequence - 2 - , - 3 - and - 4 - (1.5 Nm).
Right Trim, Driver Side
Right Trim, Driver Side
Removing
-
Switch off ignition.
-
Remove side instrument panel cover on front passenger-side
-
Remove right trim panel on drivers side
-
Remove center cover
-
Remove bolts - 1 - , - 2 - , - 3 - and - 4 - (1.5 Nm).
