Jetta L4-1.9L DSL Turbo (BEW) (2004)
^
Support T101 49
Removing
-
Measure dimension - a - from the center of the wheel to the lower edge of the wheel housing.
-
Make a note of the measurement. This is necessary to tighten the bolts for the rear axle to the bearing bracket.
-
Install brake pedal loading device V.A.G. 1869/2.
-
Actuate the brake pedal with brake pedal loading device.
The bearing bracket should not be removed to remove the rear axle!
-
Remove bolts -1 - with vehicle standing on its wheels. Raise vehicle until the bolts are accessible.
-
Loosen wheel bolts.
-
Raise vehicle to assembly height to relieve the pressure on the coil spring.
-
Remove wheels.
-
Tighten vehicle to the lifting platform
-
Before removing rear axle, the vehicle must be fixed to the support arms of lifting platform.
