Jetta L4-2.0L (BEV) (2004)
Wheel Speed Sensor: Service and Repair
ABS ITT Mark 20 IE
ABS System Components For Front Axle, Removing and Installing
ABS System Components For Front Axle, Removing And Installing
Note: Removing and installing ABS system components is identical for FS 111 and EN 3 brake calipers.
1. ABS wheel speed sensor
-
Before inserting sensor, clean mounting hole inner surface and coat with lubricant, G 000 650
2. Wheel bearing housing
3. Hex socket head bolt, 8 Nm (70 inch lbs.)
4. Splash shield
5. Hex bolt, 7 Nm (62 inch lbs.)
6. Wheel bearing
-
Replace each time after removing
-
Removing and installing
7. Screw
8. Brake disc
9. Wheel hub with ABS wheel speed sensor rotor
-
Pressing out and in
10. Circlip
Wheel speed sensor for front axle, removing and installing
Removing
