Jetta GLX Wagon V6-2.8L (AFP) (2001)
/Page-1680001.png)
Cabin Ventilation Grille: Service and Repair
Removing cowl panel
NOTE: The cowl panel is clipped into a guide rail below the windshield.
-
Remove wiper arms.
-
Pull out rubber seal -1- and unscrew bolts -2-.
-
Remove pollen filter cover.
-
Unclip trim on inner fender (arrows) on both sides.
-
Carefully press cowl panel out upward.
Installing cowl panel
Installation is in reverse order of removal.
NOTE: The sides of the cowl panel must be inserted under the rubber strip of the cowl panel strip on the -A- pillar (arrow).
