Polo Mk3

General body repairs, exterior
Flush bonded windows
Windscreen - Assembly overview

N64-0011
  • Windscreen
    • ◆ Removing windscreen
    • ◆ Installing windscreen => Page 64-12
  • Ceramic layer
  • Dimension a = 4 mm
  • Sealing lip (component part of pre-coating)
  • PUR adhesive sealant
    • ◆ Cross section of bead:
      Width = 7 mm
      Height = 11 mm (including precoating, residual material on window glass and window flange)
    • ◆ Curing time => Page 64-28

N64-0011
  • Moulded headlining
  • Retaining plate for rear-view mirror
    • ◆ PUR adhesive
  • Eccentric
    • ◆ To adjust upper window gap
  • Surround
  • Trim strip for plenum chamber
