240 L4-2127cc 2.1L SOHC Turbo B21FT FI (1982)
Inner Fan Housing - Left Side
7. Install inner fan housing and secure with the original screws.
8. Install heater control valve capillary tube in inner fan housing.
9. Install blower motor fan wheel.
10. Connect vacuum hose to left rear floor vent shutter actuator diaphragm.
Outer Fan Housing - Left Side
11. Install outer fan housing and clips.
12. Install air duct for rear floor vent. Restore floor carpet back to it's original position.
Shutter Actuator Diaphragm Hoses
13. Connect air ducts.
14. Connect vacuum hoses to shutter actuator diaphragms.
On Right-hand (Passenger's) Side of Vehicle
