780 V6-2849cc 2.8L SOHC B280F (1987)
To cancel fault code:
Display fault code again (ground test terminal for 2 - 5 seconds).
Then ground test terminal 3 times within a 1.5 - 5 second period for at least 0.25 seconds each time.
Note:
Spade connectors should be connected to both ends of lead used for grounding. Each grounding should be distinct and not too short.
Note:
Do not switch off ignition between displaying fault code and cancelling code.
Lamp will go off for 4 seconds, then go on again for 3 seconds to confirm cancellation and then go out.
If SRS lamp stays on, a fault has not been remedied. Display fault code again and remedy fault. Refer to separate SRS Service Manual as necessary.
Cancel fault code again.
Reinstall:
-
air duct
-
carpet
-
driver's seat.
During the New car Warranty period, claims must be submitted under:
Operation Number
Labor Description
Time Allowance
884433
Crash Sensor, replace
0.2 hr
