S40 T5 L5-2.5L Turbo VIN 68 B5254T3 (2006)
-
Remove the D-post panel. First pull it off from the car body. The D-post panel is secured by four clips. Unhook the upper edge from the
headlining.
-
Pry up the cover for the mounting for the cargo net. Remove the screw underneath.
-
Fold the rear backrest forward
-
Remove the side cushion by pulling forward at the upper edge until the clips on the reverse release. Then pull the side cushion straight up.
-
Pry off the cover holding the C-post panel at the upper edge. Remove the screw from underneath
-
Remove the rubber strip at the rear edge of the rear door.
