RL V6-3.5L (2007)
Headlamp Alignment Switch: Service and Repair
AFS OFF Switch Test/Replacement
1. Remove the instrument fascia.
2. Disconnect the 6P connector (A) from the AFS OFF switch (B).
3. Check for continuity between the terminals in each switch position according to the table.
4. If the continuity is not as specified, remove the screws and replace the switch.
5. After replacement, do the adaptive front lighting control unit learning procedure.
