90 Quattro Sport V6-2.8L (AFC) (1995)
/Page-1959001.png)
Seat Heater: Electrical Diagrams
Track 1 Thru 8
Heated Front Seats - Track 1-8
COMPONENTS
G59 =
Driver Seat Heater Temperature Sensor
Z6
=
Driver's Seat Heat Element
Z7
=
Driver's Backrest Heat Element
