Setting of beep delay value - Adaption channel 136
Setting of beep delay value - Adaption channel 136
Setting of beep delay value - Adaption channel 136
This adaption channel is used to set voice prompt tone delay following mute signal.
Indicated on VAS 5051:
1 -
Enter channel number
–
Use keypad
-2-
to enter “136” for channel 136 and confirm by touching
Q
key.
Indicated on VAS 5051:
1 -
Channel 136 reading and testing
5 -
Bar set to current adaption value (e.g.: 5)
1 = 0.1sec.
2 = 0.2sec.
Up to:
25 = 2.5sec
81 = 0.1sec. + 1.5sec.
82 = 0.2sec. + 1.5sec.
Up to:
105 = 2.5sec + 1.5sec.
–
Alter adaption value with bar
→ Anchor
.
Or
–
Alter adaption value by way of direct entry
→ Anchor
.
Display on completion of adaption:
1 -
Channel 136 value X stored
