A3 Mk2

Code letters, allocation, transmission ratios, capacities
Code letters, allocation, transmission ratios, capacities
The following data can be found in the → Electronic parts catalogue.
t  Individual gear ratios
t  Gear oil specification
t  Allocation of flange shafts
t  Allocation of clutch type

Manual gearbox5-speed 0A4
Code letters FNEGQQHGN
Manufacturedfrom04.0307.0306.06
 to07.0306.0607.06
AllocationModelAudi A3 2004 ►Audi A3 2004 ►
Audi A3 Cabriolet 2008 ►		Audi A3 2004 ►
 Engine1.9 ltr. - 77 kW TDI1.9 ltr. - 77 kW TDI1.9 ltr. - 77 kW TDI
Ratio
Z1 : Z2		Final drive61 : 18 = 3.38961 : 18 = 3.38961 : 18 = 3.389
Capacity of manual gearbox (gearbox completely dismantled)1.9 ltr.
Capacity of manual gearbox → Chapter (gearbox partially dismantled)1.7 ltr.


Manual gearbox5-speed 0A4
Code letters JCRKBLLHW
Manufacturedfrom06.0603.0705.09
 to05.1005.1006.09
AllocationModelAudi A3 2004 ►
Audi A3 Cabriolet 2008 ►		Audi A3 2004 ►Audi A3 2004 ►
 Engine1.9 ltr. - 77 kW TDI1.9 ltr. - 77 kW TDI1.6 ltr. - 66 kW TDI
Ratio
Z1 : Z2		Final drive61 : 18 = 3.38961 : 18 = 3.38962 : 17 = 3.647
Capacity of manual gearbox (gearbox completely dismantled)1.9 ltr.
Capacity of manual gearbox → Chapter (gearbox partially dismantled)1.7 ltr.


Manual gearbox5-speed 0A4
Code letters LUBMDZ
Manufacturedfrom05.0901.10
 to
AllocationModelAudi A3 2004 ►
Audi A3 Cabriolet 2008 ►		Audi A3 2004 ►
 Engine1.6 ltr. - 77 kW TDI1.6 ltr. - 77 kW TDI
Ratio
Z1 : Z2		Final drive62 : 17 = 3.64761 : 18 = 3.778
Capacity of manual gearbox (gearbox completely dismantled)1.9 ltr.
Capacity of manual gearbox → Chapter (gearbox partially dismantled)1.7 ltr.
