Exploded view - drain plug and inspection plug for oil in bevel box
Exploded view - drain plug and inspection plug for oil in bevel box
  Note

The bevel box is secured to the side of the gearbox and has a separate self-contained oil filling.
A - Oil drain plug for bevel box - 60 Nm
B - Filler plug/inspection plug for bevel box: renew - 15 Nm
  A37-0675
