A4 Mk3
| Exploded view of seat longitudinal adjustment motor |
Note| t | If motor is defective, lower seat pan frame must be renewed. |
| t | For greater clarity, seat pan is shown without its padding and cover. |
| 1 - | Upper seat pan frame |
| q | Separating upper seat pan frame from lower seat pan frame and assembling → Chapter |
| 2 - | Lower seat pan frame |
| q | Different versions |
| q | Separating upper seat pan frame from lower seat pan frame and assembling → Chapter |
| 3 - | Seat longitudinal adjustment motor |
| q | With lower seat pan frame |
| q | Driver side: driver seat longitudinal adjustment motor -V28- |
| q | Passenger side: front passenger seat longitudinal adjustment motor -V31- |
| q | Cannot be dismantled; only available as a complete unit → Electronic parts catalogue |
| q | Removing and installing → Chapter |
