A4 Quattro Wagon L4-2.0L Turbo (CAEB) (2009)
/Page-753001.png)
Front Crankshaft Seal: Service and Repair
Vibration Damper Shaft Seal
Special tools, testers and auxiliary items required
‹› Locking Tool (T40098)
‹› Counter Hold Tool (T10355)
‹› Pressure Piece (T10354)
Removing
-
Remove front noise insulation.
-
Remove the coolant fan electrical connector - 1 - form the bracket and disconnect it by sliding the retainer back - arrow - and pressing the release
down.
-
Free up the electrical wiring harness to the radiator fan control module.
-
Disconnect electrical connectors - 2 - and - 3 -.
-
Remove the bolt - arrow - and the coolant fan control module - 1 -.
CAUTION!
Risk of destroying due to reversed running direction on a used ribbed belt.
