Intake Manifold: Testing and Inspection
Intake Manifold Runner Control (IMRC) Valve N316, Checking
Intake Manifold Runner Control (IMRC) Valve N316, checking
Special tools, testers and auxiliary items required
-
Multimeter V.A.G 1526 A or equivalent.
-
Test Box 105 Pin VAG1598/42.
-
Adapter Lead VAG 1598/39 VAG1598/39-1.
Test requirements
-
The fuses for the engine electronics OK.
-
The parking brake engaged.
-
The battery voltage at least 12.5 V.
-
The selector lever of automatic transmission in position "P" or "N".
-
All electrical consumers switched off (radiator fan must NOT run during test).
-
A/C switched off.
-
The fuel tank at least 1/4 filled.
-
The ignition switched off.
Procedure
-
Disconnect the electrical harness connector - 5 - from the Intake Manifold Runner Control (IMRC) Valve N316.
Checking internal resistance
-
Using the Multimeter V.A.G. 1526 A or equivalent, check the Intake Manifold Runner Control (IMRC) Valve N316 for resistance.
Intake Manifold Runner Control (IMRC) Valve N316 terminals
1 to 2
Specified value: 450 to 1000 Ohms.
If specified value is obtained:
-
Replace the Intake Manifold Runner Control (IMRC) Valve N316.
If specified value is obtained:
