A6 Quattro Sedan V6-3.2L (BKH) (2005)
/Page-8447001.png)
Interior Lighting Module: Service and Repair
Front Interior Light Module, Removing And Installing
Removing
CAUTION:
-
Switch off all electrical components.
-
Switch ignition off and remove ignition key.
-
Open eyeglass compartment - 1 - and release center covers - 2 - and - 3 - of interior/reading light - arrow -.
-
Release diffusion lens - 1 - for interior/reading light - arrow -.
-
Remove bolts - arrows -.
-
Pivot front interior light downward and remove from roof trim.
NOTE: Left arrow - is dependent on construction version.
-
Disconnect electrical harness connectors.
Installing
Installation is performed in reverse order of removal, noting the following:
