Drive Belt: Diagrams

Legend

1

Bolt

2

Retaining Plate

3

Torsion Spring

4

Bolt

5

Flanged Nut

6

Damper

7

Bolt

8

Bolt

9

Generator Pulley

10

Bolt

11

Bolt

12

Hinged Mounting Bracket

13

Bolt, 8 x 28 mm

14

Bolt, 8 x 35 mm

15

Ribbed Belt

16

Viscous Fan
