A8 Sedan V8-3.7L (AEW) (1997)
/Page-1325001.png)
Flex Plate: Specifications
Flywheel/Drive Plate Torque & Tightening Sequence
Flywheel/Drive Plate Torque & Tightening Sequence
Always replace with new bolts. Install with locking compound AMV 188 001 02. Tighten in diagonal sequence
With 3.7L Engine
60 Nm plus additional 90°
44 ft lb plus additional 1/4 turn
With 4.2L Engine
85 Nm
63 ft lbs
