A8L V8-4.2L (BFM) (2004)
Both sides
-
Release retainer tabs -arrows- and remove housing cover for high beam from headlight housing.
-
Pull holder -arrow- for parking light out of headlight housing.
-
Pull out bulb for parking light out of holder.
Installing
Install in reverse order of removal, noting the following:
CAUTION: Do not touch glass portion of bulb with bare hands. Even the smallest amount of moisture and/or contaminants from fingers that
evaporates on the bulb during operation can cause the glass to cloud over.
-
Press holder into reflector until it engages.
-
Close housing cover.
Left headlight:
-
Top up power steering fluid and bleed steering system.
Right headlight:
-
Fit top part of air filter housing.
Both sides
-
Reconnect battery.
Tightening torque
Component
Nm
Power steering reservoir to holder
9
