A8L V8-4.2L (BFM) (2004)
-
Pull off retaining strip for connectors -arrows- and take connectors from fuse box.
-
Disconnect multi-pin connector -1-.
NOTE: Fuse assignments
Installing
Install in reverse order of removal, noting the following:
NOTE: Re-attach all cable ties at the same locations when re-installing.
-
Reconnect battery.
Tightening torques
Component
Nm
Fuse box to instrument panel central tube
3
Knee airbag bracket to instrument panel central tube
3(1)
(1) Always replace nuts
